SmallHD Vision 17″ 4K HDR Monitor (open Box)

Overview

Vision 17 is built for the mobile filmmaker. Compact, durable, and lightweight, this monitor is capable of traveling to any on-set environment.

Vision 17 – with a 3840×2160 resolution-screen – employs the same SmallHDR dual-modulation hardware as Vision 24. The 17-inch FALD counterpart boasts 1792 individual LED zones, with 1000+ nits of brightness to achieve perfect uniformity in contrast and latitude, with even deeper blacks and greater highlight detail. A 10-bit color depth ensures a color-accurate look at your production.

The Vision 17 features four 12G SDI inputs and outputs as well as one HDMI 2.0 input. The Unibody Smart Chassis offers a Dovetail Mounting Rail for battery and accessory mounting, interchangeable mounting points, and 2x 2-pin accessory power outputs. Hot-swappable dual inputs allow you to add on Gold Mount or V-Mount battery plate attachments.

Meet Our Smart PageOS Software

With the power of SmallHD PageOS software, build customized Page Profiles, and utilize all of the dependable SmallHD features such as personalized frame guides, Focus & Exposure Assist, high-resolution 3D LUT overlays, histogram, vectorscope, waveform, and more.

Features

• 17″ UHD 4K monitor
• 1,000,000:1 contrast ratio
• 1000 cd/m² brightness
• Four 12G/6G/3G/HD-SDI inputs and four 12G/6G/3G/HD-SDI outputs
• One HDMI 2.0 input and one HDMI 2.0 output
• SD card slot for 3D LUTs
• One RJ45 Ethernet port
• One RJ45 GPI port
• 110mm VESA mounting on the back
• Thirty-six 1/4″-20 mounting threads on top and sides
• Smartrail mounting options
• 1/4″-20 and 3/8″-16 cheese-style mounting sticks included

OS4.1



• Internal calibration wizard
• Color pipe color-space formatting
• Settings dashboard for easy access to common settings
• Preconfigured pages
• Page tabs
• Customizable false color overlays
• Customizable 4K waveform with region-of-interest highlighting
• Improved function buttons
• Pixel zoom, focus assist, peaking
• Total UI overhaul

Power Options



• One 3-pin XLR, 12-34V, 18A maximum
• Two 2-pin LEMO 12V, 2A outputs
• Two USB Type-A 5V, 2.4A outputs
• Two USB Type-C 5V, 1.5A outputs
• Separately available V-mount or Gold mount battery plates
• Requires 26V+ battery
• XLR and battery options are hot-swappable
