Panasonic LUMIX BGH1 4K Box Camera

Overview

Expanding the boundaries of the Lumix camera lineup, the Panasonic Lumix BGH1 introduces a modular, box-style design tailored for versatile production needs. Its compact and lightweight form factor makes it a top choice for gimbal and drone applications, as well as for broadcast, live streaming, vlogging, and cinematic projects.

At the heart of the BGH1 is a 10.2MP Micro Four Thirds sensor paired with an MFT lens mount, delivering exceptional flexibility and performance. With a wide dynamic range of 13 stops, it adeptly handles challenging lighting conditions. The camera supports video recording at resolutions up to 4K60 and integrates professional-grade workflows, including VariCam Look profiles such as V-Log L and Cinelike. It also features dual-native ISO technology powered by the Venus Engine, providing superior low-light performance.

Additional highlights include support for anamorphic lenses, Hybrid Log-Gamma (HLG) for enhanced color rendering, and advanced autofocus for precise focus control. The BGH1’s versatility is further amplified by its array of remote control options, power solutions, and compatibility with multicamera setups, making it an excellent choice for mobile production environments. Whether for creative or professional projects, this compact cinema camera packs robust features into its innovative design.

Features

• M4/3 10.2MP MOS sensor
• Anamorphic video support
• MFT lens mount
• 13 stops of dynamic range
• Dual native ISO
• Lightweight at 1.2 lb
• Internal fan to keep camera cool
• Measures less than 4″ square for lightweight applications on drones or gimbals
• HDMI 2.0 and 3G-SDI video outputs
• Record up to 4K60 10-bit 4:2:2 to SD cards or HDMI/3G-SDI outputs simultaneously
• Unlimited recording time
• USB 3.1 Gen 1 Type-C input for control with LUMIX Tether app
• 2.5mm LANC input for camera control
• Gigabit Ethernet via RJ45 for remote control and PoE+ power support
• Direct IP streaming with a future firmware update
• Wi-Fi and Bluetooth support to control the camera using a smartphone or tablet
• Integrated stereo microphone, 3.5mm mic input, and 3.5mm headphone output
• The optional DMW-XLR1 XLR adapter can be installed using the camera’s hot shoe
• Four programmable Fn buttons
• Tally lights on front and rear
• Genlock BNC input/output
• Timecode BNC input/output
• Dual SD card slots
• Included 12 VDC power adapter
• Integrated VBR battery mount
• Cable lock

In The Box

Panasonic Lumix BGH1 Box Cinema Camera
Power Adapter
Cable Lock
