Original price was: $387.00.$98.99Current price is: $98.99.
- 24.2MP Full-Frame MOS Sensor, L Mount
- 4K MP4 & MOV H.264/H.265/HEVC Recording
- Dual Native ISOs, ISO Auto Mode
- V-Log Capture, 14+ Stops Dynamic Range
- 3G-SDI & HDMI Out, PoE+ LAN, USB-C
- Seamless Integration with Panasonic PTZs
- Color Compatible with AW-UE160 Camera
- NDI HX2, RTMPS & SRT IP-Compatible
- Face, Eye & Body AF Recognition
- Timecode I/O, Genlock, 2 SD Card Slots
- High quality products, hassle-free returns.
- Safe Transactions, Always
- fast shipping
- Shop with confidence, enjoy free returns.
Overview
The Panasonic AW-UB50 4K Multipurpose Box Camera redefines versatility with its exceptional full-frame imaging capabilities, delivering cine-style capture in a sleek, modular design. Tailored for gimbal and drone operations, it is equally at home in broadcast, live streaming, vlogging, and cinematic productions. Seamlessly compatible with Panasonic PTZ cameras, it supports NDI HX2 and offers advanced real-time autofocus and precise subject tracking. Featuring a 24.2MP full-frame MOS sensor, a Leica L lens mount, and an expansive 13-stop dynamic range, this digital cinema camera excels at handling even the most dramatic lighting transitions with ease.
The 4K multi-purpose camera AW-UB50 delivers high-quality video and simplifies video production process whether it is corporate, education or live entertainment. Delivering stunning, vivid colour reproduction, the UB50 uses a 24.2-million pixel full-frame MOS sensor and supports IP-based transmission standards such as NDI® HX2[1].
The UB50 has been optimised for cinematic video production, featuring a shallow depth of field. The model offers real-time recognition autofocus technology, enabling the camera to automatically identify the subject and keep them in focus.
When linked with remote camera systems on the same network, the UB50 is fully compatible with Panasonic’s AK-HRP1010 remote operation panel, with future support planned with the AW-RP150GJ remote camera controller and Panasonic live switchers. The cameras can also act as a tally control. By installing a colour profile compatible with the Panasonic AW-UE160 4K integrated camera, it is easy to match colours in mixed operation with remote cameras.
Features
- 24.2M full-frame MOS sensor for emotional and cinematic video (AW-UB50)
- Wide dynamic range with V-Log (AW-UB50: 14+ stops)
- Compact design (height, width & depth each less than 10cm, excluding lens)
- Unified IP control protocol compatible with Panasonic PTZ camera systems
- Compatible with Media Production Suite for multi-camera setups with PTZ cameras
- Planned support for IP transmission standards including NDI® HX2, RTMPS, and SRT
In The Box
Panasonic AW-UB50 4K Multipurpose Box Camera
AC Adapter
Limited 1-Year Manufacturer Warranty
Specifications
| Lens Mount |
L-Mount |
| Lens Communication |
Yes |
| Sensor Resolution |
Actual: 25.3 Megapixel Effective: 24.2 Megapixel |
| Image Sensor |
35.6 x 23.8 mm (Super35) MOS |
| Image Stabilization |
No |
| Built-In ND Filter |
No |
| Capture Type |
Stills & Video |
| Shutter Type |
Electronic Rolling Shutter |
| ISO Sensitivity Range |
160 to 800 (Extended: 160 to 51,200) 400 to 2000 (Extended: 400 to 25,600) |
| Advertised Dynamic Range |
14 Stops |
| Fast-/Slow-Motion Support |
Yes |
| Gamma Curve |
HDR-HLG, Panasonic V-Gamut, Panasonic V-Log, Rec 2100 HLG, Rec709, V-Log |
| Built-In Microphone |
Stereo |
| IP Streaming |
Yes |
| Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC (UHS-II) [V90 or Faster Recommended] |
| Video I/O |
1x BNC (3G-SDI) Output 1x HDMI (Unspecified Signal) Output |
| Audio I/O |
1x 1/8″ / 3.5 mm TRS Stereo Mic/Line Input on Camera Body 1x 1/8″ / 3.5 mm TRS Stereo Headphone Output on Camera Body |
| Other I/O |
1x USB-C 1x BNC (Timecode) Input/Output 1x BNC (Genlock) Input/Output 1x RJ45 (LAN) Input/Output |
| Wireless |
No |
| Mobile App Compatible |
No |
| Global Positioning (GPS, GLONASS, etc.) |
No |
| Type |
Optional, Not Included |
| Focus Type |
Auto and Manual Focus |
| PoE Support |
PoE+ 802.3at |
| Shoe Mount |
1x Hot Shoe |
| Tripod Mounting Thread |
2x 3/8″-16 Female (Bottom) |
| Accessory Mounting Thread |
9x 3/8″-16 |
| Material of Construction |
Aluminum |
| Dimensions (W x H x D) |
3.7 x 3.7 x 3.1″ / 9.3 x 9.3 x 7.8 cm (Without Protrusions) |
| Weight |
1.3 lb / 585 g (Body Only) |
